Studio separates a document’s design, business data and delivery decision. A published template version and a validated mapping can generate exact PDFs; neither operation authorizes sending them.
Scroll across the diagram on smaller screens, or open the full-size view.
Read the flow as text
- Parsed source data passes through an explicit mapping profile. A concrete template version and settings join those mapped inputs in a generation job, which records artifacts and provenance.
- Uploaded originals retain their identity and exact stored bytes under the applicable access and retention rules. Adding a postal address page creates a separate derived PDF; the original PDF is not an imported Studio template input.
- Derived documents still need applicable scan, validation and preview checks before later immutable approval and separate dispatch acceptance. Generation itself grants no delivery authority.
The diagram reference connects this logical pipeline with the system and dispatch views, including downloadable sources.
Template authoring and publication
Templates use a typed, engine-independent envelope with a business schema, bindings and visual definition. The embedded editor and programmatic authoring share the same validation rules. Demonstration templates are synthetic starting points; creating a private copy makes an independent editable object.
Saving checks the current revision and edit permission. Publishing creates an immutable version for generation. Sharing a template does not share a dataset, mapping or generated private PDF. Owner removal hides the template from future library/generation use while retaining existing versions, PDFs and history.
DOCX import is a bounded conversion to editable blocks with warnings, not a promise of faithful Microsoft Word round trips. Rendered output, rather than the editor canvas alone, is the evidence for pagination, tables and fonts.
Preserve the source; make interpretation explicit
CSV, XLSX, JSON and XML originals remain private. Profiling preserves raw strings, cell coordinates, source options and measured issues. The pure data parser has no storage, tenant-selection, billing, dispatch or network authority.
A mapping selects sheets, header rows, field paths, types, exclusions, date/number conventions and optional grouping/joins. Headers and structural signatures detect changed source structure. A mapping update creates a new validated version; it does not silently reinterpret an already generated document.
- Postal codes and identifiers preserve leading zeros.
- Exact decimal values remain strings, or convert to explicitly scaled integer minor units; numeric mapping performs no implicit floating-point rounding.
- Formula text is never executed. Explicit cached-value use does not recalculate the workbook or attest that its cached result is current.
- Joins require explicit keys/cardinality; missing, duplicate, orphaned or conflicting data becomes an issue rather than an inferred relationship.
- Mapping paths do not permit user scripts, arbitrary expressions or network calls.
New generated root sheets use Data; repeated XML child sheets use Data.<path>.
Compatibility with historical Données names applies only to parser-generated
names with established provenance. XLSX sheets and explicitly named JSON tables
require exact matching; matching headers never authorize selecting another table.
An absent mapping or join sheet produces MISSING_SHEET and requires review.
Older JSON profiles without naming provenance also require exact names: use the
retained name, or import the source again and revalidate the mapping. Lookup
does not rewrite original bytes, saved profiles, plans or source-cell provenance.
Validation, generation and provenance
A complete deterministic validation produces either usable normalized records or issues requiring review. It records exclusions and per-field/source-row provenance. Logical documents can contain repeated line items without confusing those rows with separate recipients.
A generation job binds the selected template version, mapping/data inputs and options. The private renderer produces independent PDFs that enter the ordinary verification path. Each result retains its own status and provenance, so one record failure does not erase the successful PDFs or justify guessing its data.
Distribution freezes a deliberate selection
Preparing distribution creates ordinary dispatch preparations from generated results. It preserves exact destinations and channels; repeated values do not authorize merging, deduplicating or switching a recipient’s channel.
The first distribution plan freezes its generation batch and prevents failed-record retries, including records outside the selected subset. Finish desired retries before creating that plan. Resuming distribution continues preparations in the frozen plan; it does not reopen generation, approve sends or retry unknown provider outcomes. A later regeneration requires a new batch.
Optional suggestions remain proposals
AI-assisted template/schema/mapping suggestions require explicit configuration, transfer consent, current authority, revision and budget. Upload/profiling alone performs no inference. The server rechecks relevant permissions and consent both before the provider call and before returning a result. Revoked access or a concurrent edit blocks stale suggestions.
A proposal is never automatically applied, published or sent. Manual authoring and external-assistant mappings remain usable without the internal AI adapter. The dispatch lifecycle still governs final communications.
